2022 Norstar WESTERN HAULER Truck Bed

Description

Western Hauler Truck Bed

The WH is our top of the line bed. The Norstar Western Hauler Bed is sure to win first in class when you combine with your first class hauling rig. This bed comes equipped and ready to impress loaded with diamond plate and coated in gloss black powder coat. Accessories are abound and the details have been sweated to ensure spectacular fit and finish. But this bed is not all show, it has the same rugged construction as every Norstar bed and can haul anything your rig can pull. We have put just about every option on this bed except the kitchen sink - standard. Go to work - in style.

SPECIFICATIONS

Steel Structural Frame
4 Runner Channels
Formed 3/16 Channel Cross Members
Steel Tube Head Rack w/ Cross Bars, Tail & Rev. Lights
Steel 1/8 Diamond Plate Floor
Built in Gooseneck Ball Mount w/ Diamond Plate Lid
Skirted Rear Bumper w/ Anti Slip Step
Receiver Hitch Ready
Polished Stainless Smooth Flare Fenders
Aluminum Trim package
Aluminum Cast Tail Light Housing
Aluminum Cast License Plate Housing
Aluminum Cast Fuel Fillers Angled
Side Swing Tool Box Doors w/ Chrome Hinges
4 Recessed D-Rings
18" Gooseneck Trough
Dove Tail
Premium Powder Coated Black
Chrome Accent Lighting
2.5 LED Reflective Marker Lights
4 Clear 6 Oval LED Reverse Lights
6 Red 6 Oval LED ST/TL/TN Lights
Single LED License Plate Light
All Lighting DOT Approved
Molded Sealed Harness w/ Resistor
4 & 7 Way Receiver Female Plug w/ Adaptor

SIZE GUIDE

Use this guide when ordering your Norstar truck bed. Please observe the measurements of each dimension and check before placing your order.

Length: Measurement from cab to end of frame.
Width: Measurement from outside of tire to outside of tire
CTA: Measurement from cab to axle
Runner: Measurement from outside of frame to outside of frame at the rear of the frame.
Models: ST, SF, SR, SD
Order Method: Model x Length x Width x CTA x Runner
Example: ST 9'4"L x 97"W x 60"CTA x 34" Runners (Add options) Note: 11' long beds will have 84" CTA

Ford

1998-Present

Dually -- 8'6"L x 97"W x 56" CTA x 38" Runners
Single Wheel Long Wheel Base -- 8'6"L x 84"W x 56"CTA x 38" Runner
Single Wheel Short Wheel Base -- 84"L x 84"W x 40"CTA x 38" Runner
Cab & Chassis -- 9'4"L x 92"W x 60"CTA x 34" Runners
F-350 takes a 92"W
F-450 & 550 are 94" & 97"W with Standard Headache Rack
2015 F650 Runners 34.5"

GM / Chevrolet

2001-Present

Dually -- 8'6"L x 97"W x 56"CTA x 42" Runners
Single Wheel Long Wheel Base -- 8'6"L x 84"W x 56"CTA x 42" Runner
Single Wheel Short Wheel Base -- 84"L x 84"W x 42"CTA x 42" Runner
Cab & Chassis -- 9' 4"L x 90" or 92"W x 60"CTA x 34" Runners
(Prior to 2000 measurements will be required)
4500 & 5500 is 94"W with 60" Headache Rack

Dodge

2003-Present

2007 Cab and Chassis -- 9'4"L x 94"W x 60"CTA x 34" Runner
Mega Cab -- 84"L x 97"W x 40" CTA x 42" Runners
Mega Cab -- 84"L x 84"W x 38" CTA x 42" Runners
Dually -- 8'6"L x 97"W x 58"CTA x 42" Runners
Single Wheel Long Wheel Base -- 8'6"L x 84"W x 58"CTA x 42" Runner
Single Wheel Short Wheel Base -- 84"L x 84"W x 38"CTA x 42" Runner
2002 and earlier will have 56" CTA and 38" Runners on long bed
