2024 Kubota Standard L01 L3901 4WD Tractor

Features

Description

SPECIFICATIONS
Engine
Engine Type Direct injection, vertical, water-cooled 4-cycle diesel
Engine Power Gross: 37.5 HP (28.0 kW) | Net: 36.3 HP (27.1 kW)
Cylinder Liners 3
Rated Engine Speed 2700 rpm
Displacement 111.4 cu. in. (1826 cm3)
Bore 3.4 in. ( 87 mm)
Stroke 4.0 in. (102.4 mm)
Power Take Off
PTO Type Rear: Live-continuous running
PTO Power, Rated Engine Speed 32.1 HP (23.9 kW) | 540/2425
Drivetrain
Transmission Gear shift with synchronized shuttle, 8 forward and 8 reverse
Steering Integral type power steering
Clutch Dry type dual stage
Brakes
Brake System Type Mechanical, wet disc type
Wheels & Tires
Tires, Front Specification AG Standard: 7.2 - 16
Tires, Rear Specification AG Standard: 11.2 - 24
Tire Tread Thickness, Front 43.1 in (1095 mm)
Tire Tread Thickness, Rear 43.8 in. (1115 mm) / 47.1 in. (1195 mm) / 50.8 in. (1290 mm)
Battery
Battery 12V, RC: 110 min, CCA: 580 A
Electric
Alternator 12V, 40A
Operational
Operating Speed Traveling with standard AG tires(Forward / Reverse): 1.1 mph (1.7 km/h) - 13.2 mph (21.2 km/h) / 1.1 mph (1.7 km/h) - 13.1 mph (21.1 km/h)
Hydraulics
Hydraulic Type Lift control type: Position control
Hydraulic Flow Pump Main: 6.8 gpm (25.7 l/min) | Pump PS: 4.1 gpm (15.6 l/min)
Maximum Pressure System: 165 kgf/cm2 (16.2 MPa)
Chassis
Hitch/Type 3-point: Category I
Dimensions
Overall Length w/o 3P: 107.9 in. (2740 mm)
Overall Width min.tread: 55.1 in. (1400 mm)
Overall Height (with ROPS) 91.7 in. (2330 mm)
Wheelbase 63.3 in. (1610 mm)
Ground Clearance Min.: 13.4 in. (340 mm)
Turning Radius Min. (w/brake, 4WD disengaged): 8.2 feet (2.5 m)
Capacities
Fuel Capacity 11.1 US gal. (42 l)
Lift Mechanism At lift points: 1985 lbs. (900 kg) | 24 in. behind lift points: 1433 lbs. (650 kg)
Weights
Weight with ROPS: 2767 lbs. (1255 kg)
All pictures shown are for illustration purpose only. Actual product may vary.
